CATS- MIST (EECE) team's visit to BRB Cable Industries Ltd Factory at Kustia, to inspect partial discharge, high voltage withstand, insulation, DC resistance etc of 11KV 300 & 500 RM cable
About CATS–MIST (EECE)
CATS-MIST (EECE) was established in 2017 by EECE Department with a view to providing consultancy, advisory and testing services to public and private organizations including personal in the areas of electrical, electronic and communication engineering and to conduct collaboration and research activities with national and international academia and industry. With the availability of expert manpower, infrastructure and lab facilities, the outfit is capable to provide consultancy service related to vetting/ evaluation of technical specification, carry out field test, inspection/survey and vetting of design, drawings, test reports etc. in respect of electrical, electronic, and communication equipment as per the national and global standards.
Read MoreReport Verification
Concerned about ‘quality & safety’ and provides the most reliable services
793+
Clients
282+
Tests
42+
Experts
CATS–MIST (EECE)
Trusted By
.png)
.png)
.png)
.png)
Our Landmarking Projects
CATS–MIST (EECE) provides strategic solutions through advanced research and sustainable infrastructure development across the nation
CATS- MIST (EECE) team's factory visit in Basic Power Engg Ltd at Tongi, to inspect and test LT /HT Panel and Load Break Switch (LBS) of 11 /0.415 KV Sub-station of Mirpur Cantonment
CATS- MIST (EECE) team was carrying out a performance assessment on a 1000 kVA CRT transformer at factory site
CATS- MIST (EECE) team was ssessing a 1000 KVA CRT transformer in presence of JAICA consultant
Ongoing Project
⚡ 33/11 kV, 10/14 MVA Substation Project – Bangladesh Ordnance Factory (BOF), Gazipur
EECE Dept of MIST is currently providing consultancy support for the design, installation, testing, and commissioning of a 33/11 kV, 10/14 MVA substation at the Bangladesh Ordnance Factory (BOF), Gazipur.
The consultancy scope covers the entire project lifecycle, including:
- Conceptual SLD development for the client.
- Technical and financial vetting of tender documents.
- Bidders offer evaluation for both technical and commercial proposals.
- Design review, approval, and certification of civil and electrical works.
- SCADA system overview and integration support.
- Supervision of all civil works related to the substation.
- Inspection of supplied equipment based on test and quality reports.
- Supervision of substation erection, testing, commissioning, and performance validation.
- Preparation of completion reports, trial-run oversight, and clearance certification.
Glimpses of modern testing equipment
Relay test set Ponovo, China
Used for measuring relay trip time.
High voltage testing equipment India
Used for partial discharge test for transformer, cable, lightning arrestor, insulator etc.
Voltage- up transformer
Used for full load loss of power transformer, distribution transformer etc.
CT/PT test with variac & current injector
Used for ratio, insulation, polarity test of CT/PT; loading test of MCB, MCCB, VCB, ACB, power cable etc.
High Voltage Impulse Generator HIGHVOLT, Germany
Impulse test for applied voltage: 75KV, 170KV, 232KV, 300KV etc. Can perform power lightning withstand test of distribution transformer 11/0.415 KV up to 5 MVA, power transformer 33/11KV up to 50 MVA, cable, lightning arrestor etc.
High Voltage Test Set Megger, Germany
Can perform power frequency withstand test and measure breakdown voltage, puncture voltage etc. up to 200 KV.
Insulation Test Set Megger, UK
Measures insulation resistance up to 10 KV. Capable of timed insulation resistance, Polarization Index (PI), Stepped Voltage (SV), Dielectric Absorption Resistance (DAR), Dielectric Discharge (DD) tests.
Portable Oil Test Set Megger, UK
Measures breakdown voltage of transformer oil up to 100 KV.
Loss Measurement Test Bench Yakogawa, Japan
Measures load loss, no-load loss, harmonic test, over induced tests etc. Capable of tests on distribution transformer 11/0.415KV, 5MVA; power transformer 33/11KV, 50MVA; and auxiliary transformer.
Megger Portable Power Quality Analyzer Megger, UK
Measures power parameters (KW, KVAR, KVA, DPF, TPF), energy parameters (KWH, KVARH, KVAH), voltage/current sags and swells, transients down to 1 ms, harmonics, phase angle deviation etc.
Induced over voltage test set NTPL, India
Tests withstand capability at double voltage, double/triple/quadruple frequency of power and distribution transformer for 60 seconds.
Electrostatic Voltmeter Phenix, USA
Measures voltage up to 40 KV.
Digital Clamp on Power Meter Yakogawa, Japan
Measures voltage up to 600V and current up to 1000 A.
Earth Leakage Clamp Meter Megger, UK
Measures leakage current during high voltage application up to 300A.
